anti static PET sheet roll for thermoforming electornics blister tray

Pulixin is an excellent and leading plastic sheet Manufacturer & factory in China. We have advanced technology and equipment, mature foreign trade and export experience, and have established good cooperative relations with customers in more than 60 countries. Free samples supply, OEM & ODM accepted

  • Brand: PULIXIN
  • Origin: Shanghai, China
  • MOQ: 5 tons
  • Thickness: 0.18~1.8mm
  • Width: 300~1400mm
  • Application: Thermoforming
  • Send Inquiry

    Description

    The purpose of using anti-static PET is to take advantage of the characteristics of anti-static PET and conductive PET and effectively eliminate the forehead spark caused by electrostatic charge in electronic components, so as to minimize the potential risk.When the electronic components are in operation, because of the current running on the surface, electric ions will produce electrostatic sparks with different electric charges. When the electrostatic spark is small, it has little influence on the electronic components, but when the electric spark accumulates to a certain extent, it will produce powerful instantaneous current and cause circuit fire, or even the risk of explosion.


    Thickness: 0.25-1.5mm
    Max Width:300~ 1200mm
    Color: transparent,black
    Density: 1.33~1.34g/cm3
    Certification:ROHS,MSDS,TDS,SGS,ISO9001
    Raw Material:100% raw material
    Advantage:environmental friendly
    Sample: A4 size or free provide 10kg for test quality
    MOQ: 5 tons
    Packing:packing in rolls and plastic pallet,pp woven with PE film and strape on pallet for each roll
    Core Diameter: 3 inch or 6 inch depend on customer requirement
    Applicaion Industry:Food packaging,electronic packing,cosmetic packaging,toy packing and so on.
    Features: Uniform thickness, smooth surface/beautiful sand ripples, no grains, contamination control and good processing performance.


    Product parameters

    A-PET SHEET
    Data Sheet
    PROPERTY UNIT 抗静电
    (Antistatic )
    THICKNESS OF FILM TESTED mm 0.25~1.8
    DENSITY g/cm3 1.35
    HAZE. % 2.0(0.3mm)
    TOTAL LIGHT TRANSMITTANCE % 89(0.3mm)
    TENSILE STRENGTH @YIELD
    MD kg/cm2 >450
    TD kg/cm2 >450
    TENSILE MODULUS OF AUTYOUNG
    MD kg/cm2 >17000
    TD kg/cm2 >17000
    ELONGATION @YILED
    MD % >3.0
    TD % >3.0
    DART IMPACT
    LOAD CELL 15KN g/mm >1600
    DIACLAMP
    THERMAL
    GLASS TRANSITION TEMPERATURE (℃) 68
    CRYSTAL TEMPERATURE (℃) 125
    MELITING TEMPERATURE (℃) 248
    RECRYSTAL TEMPERATURE (℃) 181
    ANTI-STATIC RESISTTVTTY   109-1011
    RESISTTVTTY, SURFACE(HUMIDITY(50%)   25℃) (Ω)

    Why Choose Pulixin

    PULIXIN is an excellent leading PP plastic sheet roll manufacturer in China. Our factory covers an area of ​​more than 10,000 square meters and has 4 rigid polypropylene sheet production lines with international advanced equipment. It can produce 3,000-5,000 tons of PP plastic sheets per month, and the maximum storage capacity exceeds 10,000 tons.
    High Level Factory
    high level factory
    1, 6000㎡ Area
    2, 10 co-extrusion lines
    3, 15 years experience
    4, 2300+ regular customers
    Considerate Service
    Considerate Service
    1, Quick reply to inquiries
    2, Free sample on paying the postage
    3, Strong capacity, short production and fast delivery
    4, Factory inspection acceptable
    5, OEM Support
    Strict Quality Control
    Strict Quality Control
    1, Thickness error:+-0.1mm
    2, Weight erroe:+-1kg
    3, Antistatic impedance: +-0.1Ω
    On Time Delivery
    On Time Delivery
    1, Production: 1days after prepayment
    2, Delivery: 5days after final payment
