Thermoforming Blister Plastic PET Sheet

Pulixin is an excellent and leading plastic sheet Manufacturer & factory in China. We have advanced technology and equipment, mature foreign trade and export experience, and have established good cooperative relations with customers in more than 60 countries. Free samples supply, OEM & ODM accepted

  • Brand: PULIXIN
  • Origin: Shanghai, China
  • MOQ: 5 tons
  • Thickness: 0.18~1.8mm
  • Width: 300~1400mm
  • Application: Thermoforming
  • Send Inquiry

    Introduction of thermoforming blister plastic Pet sheet

    Thermoforming blister plastic PET sheet is a type of plastic material that is commonly used in the packaging industry to create clear and durable blister packs. PET (Polyethylene Terephthalate) is a thermoplastic polymer resin that has excellent clarity, toughness, and barrier properties. It is widely used in the packaging of food, pharmaceuticals, and other consumer goods.

    The thermoforming process involves heating a PET plastic sheet until it becomes soft and pliable, then stretching and molding it into the desired shape using a mold. The molded plastic sheet is then cooled and trimmed to the appropriate size.

    Thermoforming PET blister sheets are commonly used for packaging products that require high visibility and protection, such as electronics, toys, cosmetics, and medical devices. The clear and glossy surface of the PET sheet provides a visually appealing display of the product, while the rigid and durable structure protects it from damage during shipping and handling.

    Thermoforming PET blister sheets can be customized in terms of thickness, size, shape, and color to meet the specific packaging requirements of different products. They are also recyclable and environmentally friendly, making them a popular choice for sustainable packaging solutions.

    Thermoforming Blister Plastic PET Sheet
    Thermoforming Blister Plastic PET Sheet

    Advantage of thermoforming blister plastic Pet sheet


    High Transparency

    Stronger impact resistance

    Food Grade Plastic

    Good Thermoforming

    Low temperature resistance



    Easy Secondary processing

    Chemical Resistance

    Type of thermoforming blister plastic Pet sheet

    APET (Amorphous Polyethylene Terephthalate) Plastic Sheet

    APET is a thermoplastic and environmentally friendly plastic product. Its side material and waste can be recycled. The chemical elements it contains are carbon, hydrogen, and oxygen like paper, which is a degradable plastic. After the packaging products made of this material are discarded, they eventually become water and carbon dioxide.

    PETG (Polyethylene Terephthalate Glyco) Plastic Sheet

    PETG sheet has outstanding toughness and high impact strength, its impact strength is 3-10 times that of modified polyacrylates, and it has a wide processing range, high mechanical strength and excellent flexibility, and is more transparent than PVC High, good gloss, easy to print and has environmental advantages.

    GAG Plastic Sheet

    GAG is a three-layer composite sheet. It is a three-layer composite sheet produced by co-extrusion of the middle layer APET and the upper and lower layers of PETG raw materials in an appropriate proportion. It is especially suitable for packaging boxes that need to be bonded by high-frequency heat sealing and glue

    RPET Plastic Sheet

    RPET (recycled polyethylene tetraphyte) sheet is a new type of environmentally friendly recycled sheet, which is extracted from discarded plastic products. It can effectively save raw materials and is beneficial to environmental protection.

    Features of thermoforming blister plastic Pet sheet

    Thermal properties of pure PET plastic heat resistance is not high, but after enhanced treatment, greatly improved, at 180℃ mechanical properties than PF laminate is better than enhanced thermoplastic engineering plastics heat resistant varieties.

    PET has good heat aging resistance, embrittlement temperature of -70℃, at -30℃ still has a certain toughness.

    PET is not easy to burn, the flame is yellow, it is dripping. Advantages: PET plastic has excellent abrasion resistance, dimensional stability and electrical insulation.

    The bottle made of PET has been widely used for its strength, transparency, non-toxicity, anti-permeability, light weight and high production efficiency.

    Non-toxic, weather resistance, chemical resistance, good stability, high moisture absorption.

    Parameter of thermoforming blister plastic Pet sheet

    Properties Method(ASTM) Unit APET PETG GAG
    Melting Point (DSC) 251 245
    Glass Transition Temperature (DSC) 71 74 72
    Deflection Temperature (DSC) 65 74 70
    90℃ Horizonal D1204 % 1.2 9 5
    Vertical 0.5 0.3 0.4
    110℃ Horizonal 5 4.4 4.7
    Vertical 2.3 2.3 2.3
    Specific Gravity D792 g/cm³ 1.35 1.3 1.34
    Water Absorption D570 % 0.7 0.66 0.73
    Tensile Strength At Break D638 psi 8900 7890 8280
    Elongation At Break D638 % 471 6 168
    Tensile Modulus D638 10³ psi 839 618 721
    Hardness (Rockwell) D785 R 70 74 71
    Impact Strength (Dart) D1790 J/M 7200 6900 7000
    Flexural Strength
    Horizonal D790 psi 11200 7980 10550
    Vertical 10800 7980 10230
    Flexural Modulus
    Horizonal D790 10³ psi 731 500 684
    Vertical 719 583 691

    Manufacturer of thermoforming blister plastic Pet sheet

    Pulixin is a professional manufacturer of PP, PET, PS plastic sheets. The company has passed ISO9001, SGS quality system certification test certificates.

    We have an experienced professional team with 20 years of R&D, production and sales experience.

    Our technicians and designers can provide you with help and help you customize products that are satisfactory.

    Our professional quality control personnel are always before production. Monitor the production process.

    Our products have been exported to many countries and regions in the world, especially in North America, Europe and Southeast Asia.

    The high quality and integrity of our products have brought us a good reputation for long-term cooperation with customers.

    We welcome customers from all over the world. We always provide customers with the best quality products, competitive prices and perfect service.


    1. Do you provide samples ? is it free or extra ?

    Yes, we could offer the sample for free charge by freight collect.

    2.Do I need to pay the shipping cost for sample ?

    Samples Shipping: Via International Courier (DHL, Fedex, UPS, TNT or Aramex etc…)

    3. What is your terms of payment ?

    Payment>=1000USD, 30% T/T in advance ,balance before shippment. we also accept L/C at Sight .

    4. How about your delivery time?

    Generally, it will take 7 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
